Functional Over view
Specific Parameter Intro
Chapter 4
Post
Horizontal movement
to view waveform
Depends sample
memory depth
Depth
Internal storage depth
1k/2k/4k/8k
Enable
Display/hide Trigger line
cursor
ON/OFF
Source
Choose the Measurement
channel
CH A/CH B
Type
Choose the
Measurement Type
FREQ/DUTY/ RMS/
Vavg/Vpp/Max/Min
Notes: Frequency/Duty/
Root Mean Square/
Voltage Avergage/
Voltage Peak-Peak/
Voltage Maximum/
Voltage Minimum
Enable
Display/Hide
measurement window
ON/OFF
Source
Choose the Measurement
channel
CH A/CH B
Type
Choose the Measurement
Type
FREQ/DUTY/RMS/
Vavg/Vpp/Vmax/ Vmin
Notes: Frequency/Duty/
Root Mean Square/
Voltage Avergage/
Voltage Peak-Peak/
Voltage Maximum/
Voltage Minimum
Enable
Display/Hide
measurement window
ON/OFF
Page1
Oscillo
Menu Item
Options
Annotation for Functions
Description
Page2
Measure
