Item /
Assembly
Part # Description Qty.
AA 2994864 BAG SEMBLY - (BOLT, NUT, WHERS) 1
1 2263462 BOLT-MOUNTING-1/4X2 W/G 6
2 2261713 WHER-1/4 6
3 2263103 NUT NYLOK 1/4-20 MTG 6
4 2301720 WHER-MOUNTING RUBBER 6
5
✖
MOTOR SEMBLY 1
6 2390800 t NYARD, REMOTE W/ RABEENER 1
7 2994075
t REMOTE Y, IPILOT 1
p
2397101 t MANUAL, QUICK REF., IPILOT 1.6 1
8 2994076
t REMOTE SEMBLY LINK TOUCHSCREEN 1
9 2373241
t BLE, USB REMOTE CHARGER LINK 1
10 2375901 t ADAPTER, USB DC POWER LINK 1
11 2996400
t HEADING SENSOR SEMBLY 1
12 490389-1
t BLE, H (M12-M-M12-F, 30' 1
13 2211415 BLE-EXTENSION, PD/AP 110" 1
14
2092600 PIN-DRIVE 1.06" LG (SS) 1
2262658 PIN-DRIVE 1" X 3/16" S/S 1
15
2151726 WHER-5/16 D (S/S) 1
2091701 WHER-PROP (RGE) 1
16
2053101 NUT-PROP,NYLOC (MED) 5/16 SS 1
2093101 NUT-PROP,NYLOC,LG, 3/8 SS 1
17
2091160 PROP-WW2 (3-5/8") REAMED 1
2341160 PROP-WW2 (4.5) W/ADP.RING 1
2331160 PROP-WW2 (4") W/ADP.RING 1
BB 1378131 PROP IND 2091160 WD WDG II 1
CC 1378160 PROP KIT 2341160 112# WW2 1
DD 1378132 PROP IND 233160 WD WDG II 1
EE 2994721 PED Y, TRV, W/SPOT LCK 1
FF 2994859 BAG, Y-TERROVA/V2, RUB BUMPERS 1
18 2325110 PAD, FOOT PEDAL 5
p
2327132 INALTION INRUIONS TERROVA 1
p
2397103 t MANUAL, QUICK REF., IPILOT LINK 3.0 1
13
10
4
9
12
2
3
15
16
14
17
EE
5
18
8
7
4
FF
1
6
AA
BB
CC
DD
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot or i-Pilot Link.
INSTALLING THE TERROVA
Your new Terrova comes with everything you’ll need to directly install it to the boat. This motor can be directly mounted to the
boat or coupled with a Minn Kota quick release bracket for ease of mounting and removal. For installation with a quick release
bracket, refer to the installation instructions provided with the bracket. For compatible quick release mounting brackets and
to locate your nearest dealer, visit minnkotamotors.com. To install the motor directly to the boat, please follow the instructions
provided in this manual. Please review the parts list, mounting considerations and tools needed for installation prior to getting
started. For additional product support, please visit minnkotamotors.com.
INSTALLATION PARTS LIST
8 | minnkotamotors.com
©2016 Johnson Outdoors Marine Electronics, Inc.
