8
Command MES
Function @Following the mode setting, measures one time.
@Outputs the measured value.
Control side Ë this product format
MES
This product Ë control side format
@When normal measurement
"OK00, } , }D , }D "
@When luminance and chromaticity measuring range over
(same as E0 display)
"ER10"
@
When chromaticity measuring range over (same as E0 display)
"OK11, } , }D0000, }D0000"
@When luminance display range over (same as E9 display)
"OK12, | 999999, }D , }D "
@When display out of the range display and out of the
measuring range display (over, chromaticity only) simul-
taneous occurrence (same as E9, E0 display)
"ER12"
@
When luminance display range under (same as flickering display)
"OK13, } , }D , }D "
Control sideËthis product format details
Command only
This productËcontrol side format details
@When normal measurement
Following the error check command, outputs the luminance
value Y (or luminance difference cY), chromaticity x (or,
chromaticity difference cx), chromaticity y (or chromatic-
ity difference c y).
@
When luminance and chromaticity measuring range over (same as E0 display)
Outputs only error check command.
@
When chromaticity measuring range over(same as E0 display)
Following the error check command, outputs y luminance
value Y (or luminance difference c Y), error constant.
@When luminance display range over (same as E9 display)
Following the error check command, outputs error constant
chromaticity x (or chromaticity difference cx), chromatic-
ity y (or chromaticity difference c y).
@When display out of the range display and out of the
measuring range display (over, chromaticity only) simul-
taneous occurrence. Outputs only error check command.
@
When luminance display range under (same as flickering display)
Following the error check command "OK13", outputs luminance
value Y (or luminance difference c Y), chromaticity x (or
chromaticity difference cx), chromaticity y (or chromatic-
ity difference c y).
