10
This product Ë control side format
@When normal measurement
"OK00, } , }D , }D "
@When luminance and chromaticity measuring range over
(same as E0 display)
"ER10"
@
When chromaticity measuring range over (same as E0 display)
"OK11, } , }D0000, }D0000"
@When luminance display range over (same as E9 display)
"OK12, | 999999, }D , }D "
@Display out of the range display and out of the measuring
range display (over, chromaticity only) simultaneous oc-
currence (same as E9, E0 display)
"ER12"
@
In case that the measured value is not held (same as E display)
"ER01"
@
When luminance display range under (same as flickering display)
"OK13, } , }D , }D "
Control sideËthis product format details
Command only
This productËcontrol side format details
@When normal measurement
Following the error check command, outputs luminance value
Y (or luminance difference cY), chromaticity x (or, chro-
maticity difference cx), chromaticity y (or chromaticity
difference c y).
@
When luminance and chromaticity measuring range over (same as E0 display)
Outputs only error check command.
@When chromaticity measuring range over
(same as E0 display)
Following the error check command, outputs luminance value
Y (or luminance difference c Y), error constant.
@When luminance display range over (same as E9 display)
Following the error check command, outputs error constant
chromaticity x (or chromaticity difference c x), chroma-
ticity y (or chromaticity difference c y).
@When display out of the range display and out of the measur-
ing range display (over, chromaticity only) simultaneous
occurrence. Outputs only error check command.
@When the measured value is not held (same as E display)
Outputs only error check command.
@When luminance display range under (same as flickering display)
Following the error check command "OK13", outputs luminance
value Y (or luminance difference c Y), chromaticity x (or
chromaticity difference cx), chromaticity y (or chromatic-
ity difference c y).
