Minuteman HM47B - Replacing Drive Tire

4.2 Replacing Drive Tire
Steps to be executed for wheel changing
1.
3.
Dismount drive unit at the
separation point between the
wheel support plates
Remove holder between
the plate and the brush
flange
2.
Loosen fixing screws of plate
4.
Remove the lateral
sealing plug
Loosen
fixing
screws
of
plate
and holder
sealing
plug
11
