3.3 Sealing Strips
• Check and Adjust Sealing Strips at the Broom Compartment
• In order to assure good function of the sweeper, a perfect condition and correct adjustment of the
sealin
g
stri
p
s of the broom com
p
artment are re
q
uired
,
es
p
eciall
y
in order to attain the
p
rescribed low
gp p q ,p y p
pressure (≥ 9mm water column) in the broom compartment, a clean sweeping result and the less
possible wear of the sealing strips.
•
• Proceed to adjustment of the sealing strips at the bottom of the broom compartment on level ground only.
Th l t l d li t i dj t bl i bl h l th f t li t i b t lli
•
Th
e
l
a
t
era
l
an
d
rear sea
li
ng s
t
r
i
ps are a
dj
us
t
a
bl
e
i
n o
bl
ong
h
o
l
es,
th
e
f
ron
t
sea
li
ng s
t
r
i
p
b
y con
t
ro
lli
ng
mechanism.
•
• Check the inflation pressure of pneumatic tyres and modify pressure if required.
•
•
• The sealing strip at the front folding apron has to be lightly inclined backwards and stand on the floor.
•
• Ground clearance of the left- and right-hand sealing strips is 5/64” (2mm)
•
• Ground clearance of the rear sealing strip is approx. = .20” (5mm)
• Note: Replace defective sealing strips immediately
