Minuteman HM47B - Side Brush Adjustment

3.4 Side Brush Adjustment
Adjust inclination of the side brush such that approx.
2
/
3
of the brush perimeter has contact with the floor.
For right-hand side brush this ground contact is recommended between 11 and 3 o’clock seen in direction of travel.
For left-hand side brush this ground contact is recommended between 9 and 1 o’clock seen in direction of travel.
•Adjust inclination after loosening the gear holder and by displacing in the oblong holes.
•Adjust height of the lifted side brush at the Bowden cable such that the alignment of the top edges of the belt pulleys is
approx. 10° less than vertical axis. Then the distance between the top side of the V-belt and the fairing holder is about
15mm.
•T
e
n
s
i
o
n
o
f
t
h
e
V-
be
l
t
i
s
n
ot
adjustab
l
e
but
g
iv
e
n
by
e
l
ast
i
c
f
o
r
ce
.
eso ote
be t s ot adjustab e but g e by e ast c o ce
Heightadjustment
Angle adjustment
Adjustmentofpivotingangle(displacein
theoblonghole)
Screw should axially align with the outer
border of the frame
8
