4.2 Replacing Drive Tire
13
15.
13
.
Place brush flange and
drive in straight onto the
motor shaft
Insert sealing plug
into borehole
motor
shaft
14.
Screw fastening plate
16.
Thenmaintenanceis
completed
completed
.
Driveunitmaybe
mountedtothemachine.
