COMMISSIONING
Maximum Temperature Setting
Before using the shower the maximum temperature
must be checked to make sure that it is at a safe
level. It has been preset to a safe showering
temperature under ideal conditions at the factory,
appropriate for most systems. However, site
conditions and personal preference may make it
necessary to reset this temperature.
Note! Make sure that the hot water temperature is
at least 55°C and that there is sufcient supply.
Caution! Before testing the mixer, make sure
that the hot and cold water is owing correctly by
exercising the temperature selector knob between
the cold and hot stops.
1. Turn the temperature selector knob to position
7 and test that the temperature of the water
from the shower outlet is hot enough.
2. If not, depress the override button and
carefully rotate towards position 9. If the water
temperature is still not hot enough complete
the following procedure.
3. Rotate the temperature selector knob back to
position 7.
4. Using a suitable screwdriver carefully prise
off the concealing cap and unscrew the xing
screw.
5. Pull off the temperature selector knob without
disturbing the stop assembly.
Fixing Screw
Concealing Cap
Temperature
Selector Knob
6. Replace the temperature selector knob so that
the 6 mark is in line with the stop assembly.
7. Rotate the temperature selector knob to
position 7, wait for the water to stabilise and
test that the temperature of the water from the
shower outlet is hot enough.
If the water temperature is still not hot enough
repeat the procedure until a maximum safe
temperature is achieved at position 9.
8. Ret and tighten the xing screw, ret the
concealing cap.
