Kaleido-X (4RU) Installation
The Kaleido-X is a multi-room, multi-image display processor and router in a single,
expandable chassis. This document contains physical descriptions, installation instructions
and connection information for the Kaleido-X (4RU) frame and the cards that are installed in
it.
Summary
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Mechanical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Frame and Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Kaleido-X Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Introduction
The Kaleido-X (4RU) system’s unique mix of capabilities represents the most integrated
monitoring and routing solution. As a multi-image processor, it offers the highest level of
signal flexibility. Each chassis can display 32 HD, SD or Analog inputs any number of times,
in any size, across 4 displays of any resolution and orientation.
Features
Unmatched
flexibility
Any source can be repeated to any position, to any display, at any size, at
any resolution, without blocking or grouping restrictions.
Superior display Highest quality multi-image output without compression, with superior
on-screen graphics, for the most critical live monitoring applications.
768 audio
channels
Unprecedented audio performance with the ability to monitor up to
768
channels of audio, including embedded, discrete AES, or discrete
analog.
