N/B MAINTENANCE
N/B MAINTENANCE
Battery translation board connection between M/B and battery.
Quick start buttons translation board (QSB) connection between M/B and five Buttons.
Internet quick start button translation board (IQSB) connection between M/B and touch pad, five LEDs, two Buttons.
FDD-HDD translation board connection between M/B and floppy, hard disk.
One CD-ROM connector on M/B.
1.2.11 Audio System: AC’97 CODEC CS4299
AC’97 CODEC CS4299 provides a complete high quality audio solution, Feature Include:
- MPU-401 interface
- FM synthesizer
-Game Port
- MIDI port.
- MODEM
- CD-ROM
- User-Defined GPIO
- Volume Control: Rotary VR
Stereo BTL 2x1 W Amplifiers(TPA0202) With 8 Ohm Load.
CD-ROM IDE Interface
18-bit Stereo ADC & 20-bit Stereo DAC For Record And Play Back
Programmable Sample Rates From 20Hz To 20kHz For Record And Playback
Microphone in * 1 (3.5 mm phone-jack)
Headphone out * 1: stereo (3.5 mm phone-jack and SCMS support)
