N/B MAINTENANCE
N/B MAINTENANCE
Line in * 1(3.5 mm phone-jack)
Built-in Speaker * 2 (1w, 8 ohm)
Built-in Microphone * 1
Note: For Those Input Source Not Using Should Be Set Mute In Order To Reduce Noise. Like Line In
1.2.12 IR MODULE: HSDL-3600#007
Fully Compliant to IrDA 1.1 Specifications
- 115.2 kb/s to 4 Mb/s operation
- excellent nose-to-nose operation
Compatible with ASK, HP-SIR, and TV Remote
IEC825-Class 1 Eye Safe
Wide Operating Voltage Range
- 2.7 V to 5.25 V
Small Module Size
- 4.0 x 12.2 x 5.1 mm (HxWxD)
Complete Shutdown
- TXD, RXD, PIN diode
Low Shutdown Current
- 10 nA typical
Adjustable Optical Power Management
- Adjustable LED drive-current to maintain link integrity
