20
24
3VSB
Power
25
PCIe_TVBD_RX+_R
Receive(positive)
26
Ground
Ground
27
Ground
Ground
28
V_1P5
Power
29
Ground
Ground
30
SMB_CLK_MAIN
SMbus CLOCK
31
PCIe_TVBD_TX-_R
Transmit(negative)
32
SMB_DATA_MAIN
SMbus DATA
33
PCIe_TVBD_TX+_R
Transmit(positive)
34
Ground
Ground
35
Ground
Ground
36
USB_PCH_DN9
DATA(negative)
37
Ground
Ground
38
USB_PCH_DP9
DATA(Positive)
39
3VSB
Power
40
Ground
Ground
41
3VSB
Power
42
NC
NC
43
Ground
Ground
44
3VSB
Power
45
NC
NC
46
NC
NC
47
NC
NC
48
V_1P5
Power
49
NC
NC
50
Ground
Ground
51
NC
NC
52
3VSB
Power
GND1
Ground
Ground
GND2
Ground
Ground
T A B L E 15 M INI PCI E SLOT F OR SSD/TV CARD SIGNA LS
