Mitchell MIT6501 - Software Interface Layout and Data Transfer

-23-
(D) 5KV Insulation Tester Interface Layout:
①
RS 232 Connection.
②
Main operation interface.
③
Memory saving and downloading interface.
④
Click the "Download Log from Device" button to download
the current data and statistics les.
①
③
②
④
⑥ ⑤
