6. Hold the metal counterweight at the back of the tone arm.
7. Hold the metal counterweight to keep it from moving, and then carefully rotate the front
black number ring so that 0 is in the 12 o'clock position.
8. Hold both the metal counterweight and black number ring together. Rotate them counter-
clockwise one full circle, then set the ring to 0.5 so that 0.5 on the dial is in the 12 o’clock
position. This set the tone are to 3.5 ± .5 grams of downward force (the recommended
tracking weight) for this needle.
Note: Do not turn the metal counterweight. The black number ring turns
separately.
