Mitcorp X2000 - Specifications - Probe Details; Probe Head, Material, and Illumination; Articulation, Temperature, and Resistance

- 28 -
6.0mm 360 Articulation Probe
Joystick console Dimensions (WxDxH) 139.4x193x84.2mm (w/o SR and insert tubes)
Net weight 2m:770g/ 3m:866g (approximately)
Joystick console buttons Brightness +, Brightness -, snapshot / record
Lock and move Lock / unlock switch on console
Probe head diameter 6.0mm
Probe length 2m / 3m
Probe head material Stainless Steel
Probe material Tungsten braid
Prove head length 19.3mm
Direction of View Front view
Field of View (FOV) 90°
Depth of Field (DOF) 10mm~100mm
Illumination Front / Side LEDs
Articulation angle (up/down/right/left) 2m,3mfullways≥120°
Operating temperature
In air: -10~100°C
In water: 10~30°C
Dustproongandwaterproong
Joystick console: IP 54
Insert Tube: under water 1m for 30 minutes
Relative humidity Max 95% non-condensing
Liquid resistance
Operable when exposed to machine oil, light oil or 5%
salinne solution
