8-2
If this does not resolve the problem, contact DePuy Mitek customer service.
A list of all Fault symbols and their descriptions is provided below:
There are no user defined alarms used in the VAPR system.
There are no distributed alarms used in the VAPR system.
There is no facility for disabling or silencing alarms used in the VAPR system.
All alarm conditions produced by the VAPR system are LOW PRIORITY technical alarms as
per IEC60601-1-8 table 1.
Audio alarms comply with the requirements of IEC 60601-2-2:2009.
Thermistor Electrode Alarm Descriptions
Short start: 500Hz for 75mS followed by 75mS gap repeated five times.
Short end: 500Hz for 130mS followed by 130mS gap repeated three times.
Tip Over temperature: 800Hz for 110mS followed by 500Hz for 110mS repeated while
condition occurs.
Non-Thermistor Electrode Alarm Description.
Short 65ms at 800Hz followed by 65ms at 500Hz while condition occurs and pedal pressed.
Fault
Symbol Ref Description
100 10 Software failure
100 11 ROM checksum failure
100 12 Non volatile memory failure
100 13 Memory failure
100 14 Power generation fault on start up
100 15 Power generation shutdown fault
200 10 PWM signal : shorted high
200 11 PWM signal : shorted low
200 12 MSYNC signal : shorted high
200 13 MSYNC signal : shorted low
200 14 Energy stuck high
200 15 IOUT stuck high
200 16 FOOT signal : shorted high
200 17 FOOT signal : shorted low
200 18 CUT/COAG signal : stuck high
200 19 CUT/COAG signal : stuck low
200 20 CLAMP signal error (DAC output)
200 21 BOOST signal error (DAC output)
200 22 PEAKSET signal error
200 23 PEAK signal error : stuck high
200 24 RF_DET signal error : stuck low
200 25 OVERDOSE signal error : stuck high
200 26 ENERGY signal error : stuck low
200 27 Line voltage relay error
