MITOADAPT
BRACKET INSTALLATION FOR UNIVERSAL STAND
1 MitoADAPT MAX
+
1 MitoADAPT MID
1 MitoADAPT MAX
+
1 MitoADAPT MIN
Rubber feet remain on the bottom of the MitoADAPT MAX.
Remove the hanging posts from the top of the bottom light.
Lay out panels and install brackets as shown. Two additional sets of
brackets will be included . One set will need to be installed depending
on the stand configuration (vertical vs horizontal).
*Note - see product specific user manuals / video tutorials for bracket
install instructions as the brackets vary by series-
https://mitoredlight.com/pages/user-manual
