Floor to wall mounting:
If your ADAPT XL erroneously arrives with screws in the top of the panel,
PLEASE REMOVE THESE.
Proper installation of floor to wall mount requires the 4 allen cap head
screws (see below).
Due to the size and weight of the ADAPT XL panels they should only be
installed as below:
MitoADAPT Ultimate:
Floor mount (secure to
wall with L bracket) only
MitoADAPT XL
Attention: The floor to wall mounting bracket is designed to allow the bottom
of the panel to be rested on the floor and with the top of the panel secured
against the wall. This bracket is not intended to support the weight of the
light suspended off the floor!
Panel Mounting
MitoADAPT Mega:
Floor mount or
Horizontal/vertical stand
MitoADAPT Elite:
Floor mount or Vertical
stand
