260LX/UX, 330LX/UX, 430UX, 530 UX
Brushcutter
24
Original Instructions Version August 13
Carburettor
The carburettor mixture setting has been set at the factory and will not need adjusting.
Adjusting the idle speed: If adjustment is necessary turn the T screw (a) clockwise until the
cutting head starts to move, then turn the screw T anticlockwise until the cutting head stops.
If the idle speed cannot be adjusted to stop the cutting head moving at idle, contact
your dealer for repair before use.
Safety Lock
The safety lock is to prevent the throttle lever from accidentally being engaged. The throttle lever
(b) can only be pressed in if the safety lock (c) is held down. Check if the safety lock and throttle
lever returns to its original position and the engine returns to idling when you release your hand
from the handle.
Any defects contact your nearest service agent for repairs before using the machine.
(b)
(c)
(b)
(c)
(a)
