Appliance Parts List: 26L
ID. PART No DESCRIPTION
1 MITBC431D.02.00-3 CLAMP 1
2 MITBC430D.03.02-00 HARNESS CLAMP LOOP 1
3 MIGB/T2671.2 M5X20 SCREW M5X20 1
4 MITBC430D.03.00-2 CLAMP 1
5 MIGB/T6170 M5 NUT M5 1
6 MITBC431S.03.01-00 OUTER SHAFT ASSEMBLY 1
9 MITBC431D.04.00-00 GEAR BOX ASSEMBLY 1
10 MIGB/T894.1 10 CIRCLIP (SIZE 10) 1
11 MIGB/T893.1 26 CIRCLIP (SIZE 26) 1
12 MIGB/T276 6000-2Z BALL BEARING 6000-2Z 2
13 MIC43.0116.0002 PINION 1
14 MITBC431D.04.00-1 GEARBOX 1
15 MIC43.0116.0007 TOP GUARD 1
16 MIGB/T70.1 M5X8 SCREW M5X8 3
17 MIGB/T276 6000-2Z BALL BEARING 6000-2Z 1
18 MIC43.0116.0004 GEAR 1
19 MITBC431D.04.00-3 GEAR SHAFT 1
20 MIGB/T276 6002-2Z BALL BEARING 6002-2Z 1
21 MIGB/T893.1 26 CIRCLIP (SIZE 26) 1
22 MITBC431D.04.00-6 BLADE CLAMP - LOWER 1
23 MITBC431D.04.00-5 BLADE CLAMP - UPPER 1
24 MITBC431D.04.00-8 NUT PROTECTOR 1
25 MIGB/T6177.2 M10X1.25 FLANGE NUT M10X1.25 LH 1
26 MIGB/T70.1 M6X12 SCREW M6X12 1
27 MIGB/T2671.2 M6X12 SCREW M6X12 1
28 MIGB/T2671.2 M6X25 SCREW M6X25 1
29 MITBC430D.03.00-1 DRIVE SHAFT 1
30 MITBC431D.06.01-1 SKIRT 1
31 MIGB/T845 ST4.8X13 TAPPING SCREW ST4.8X13 2
32 MITBC431D.06.00-2 LINE CUTTER 1
33 MITBC431D.06.02-00 DEBRIS GUARD 1
34 MIC43.1113.0102 SPACER 2
35 MITBC430D.06.00-1 CLAMP 26MM 1
36 MIGB/T2671.2 M6X20 SCREW M6X20 2
37 MITBC431S.05.01-1 FRONT HANDLE 1
38 MIGB/T6170 M5 NUT M5 2
39 MITBC431S.05.01-2 HANDLE BASE 1
ID. PART No DESCRIPTION
40 MITBC431S.05.01-3 HANDLE CLAMP 1
41 MITBC431S.05.01-4 HANDLE BAR 1
42 MIGB/T2671.2 M5X28 SCREW M5X28 2
43 MIGB/T93 M5 SPRING WASHER M5 2
44 MIGB/T97.1 5X12X1.5 PLATE WASHER 2
45 MIGB/T97.1 5X11X2 PLATE WASHER 1.5X11X2 1
46 MIGB/T97.1 5X12X1.5 PLATE WASHER 1
47 MIGB/T845 ST4.8X19 TAPPING SCREW ST4.8X19 2
48 MITBC022S.2.1 THROTTLE HANDLE LH 1
49 MITBC022S.2-7A FIXING CLAMP 1
50 MIGB/T70.1 M5X14 CAP HEAD SCREW M5X14 1
51 MITBC143S.05.02-12A/13A SWITCH WIRES 1
52 MITBC143S.05.02-11A CABLE SLEEVE 1
53 MITBC143S.05.02-10A THROTTLE CABLE ASSEMBLY 1
54 MITBC022S.2.2 THROTTLE HANDLE RH 1
55 MIGB/T845 ST4X10 SCREW ST4X10 4
56 MITBC022S.2-1 TRIGGER 1
57 MITBC022S.2-4 SPRING 1
58 MITBC022S.2-6 SPRING 1
59 MITBC022S.2-2 LOCK TRIGGER 1
60 MIGB/T70.1 M5X14 CAP HEAD SCREW M5X14 1
61 MITBC022S.2-7A FIXING CLAMP 1
62 MIYD38-3.01.11.04-00 ON/OFF SWITCH 1
63 MIC43.1311.0500 THROTTLE ASSEMBLY 1
64 MITBC431D.02.00-2 BLADE COVER 1
65 MITBC430D.02.01-00 NYLON HEAD ASSEMBLY 1
66 MIC43.1100.0001 BLADE 1
67 MI00.07.06.0007 HARNESS - SINGLE STRAP 1
