Mitox 26L - Page 55

26L/U, 33L/U, 43U, 53U
55
Original Instructions Version June 16
Appliance Parts List: 53U
ID PART NUMBER DESCRIPTION QTY
1 MITBC431D.02.00-3 CLAMP 3
2 MITBC430D.03.02-00A HARNESS CLAMP 1
3 MIGB/T2671.2 M5X20 SCREW M5X20 1
4 MITBC430D.03.00-2A RETAINER CLIP 1
5 MIGB/T6170 M5 NUT M5 1
6 MITBC431D.03.01-00A OUTER SHAFT ASSEMBLY 1
9 MITBC431D.04.00-00A GEAR BOX ASSEMBLY 1
10 MIGB/T894.1 10 CIRCLIP (SIZE 10) 1
11 MIGB/T893.1 26 E CLIP (SIZE 26) 1
12 MIGB/T276 6000-2Z BALL BEARING 6000-2Z 2
13 MIC43.0116.0002 PINION 1
14 MITBC431D.04.00-1A GEAR BOX 1
15 MIC43.0116.0007 TOP GUARD 1
16 MIGB/T70.1 M5X8 SCREW M5X8 3
17 MIGB/T276 6000-2Z BALL BEARING 6000-2Z 1
18 MIC43.0116.0004 GEAR 1
19 MITBC431D.04.00-3 GEAR SHAFT 1
20 MIGB/T276 6002-2Z BALL BEARING 6002-2Z 1
21 MIGB/T893.1 26 E CLIP (SIZE 26) 1
22 MITBC431D.04.00-6 BLADE CLAMP - LOWER 1
23 MITBC431D.04.00-5 BLADE CLAMP - UPPER 1
24 MITBC431D.04.00-8 NUT PROTECTOR 1
25 MIGB/T6177.2 M10X1.25 FLANGE NUT M10X1.25 1
26 MIGB/T70.1 M6X12 SCREW M6X12 1
27 MIGB/T2671.2 M6X12 SCREW M6X12 1
28 MIGB/T2671.2 M6X25 SCREW M6X25 1
29 MITBC430D.03.00-1 DRIVER SHAFT 1
30 MITBC431D.06.01-1 SKIRT 1
31 MIGB/T845 ST4.8X13 TAPPING SCREW ST4.8X13 2
32 MITBC431D.06.00-2 LINE CUTTER 1
33 MITBC431D.06.02-00 DEBRIS GUARD 1
ID PART NUMBER DESCRIPTION QTY
34 MIC43.1113.0102 SPACER 2
35 MITBC431D.06.00-1A GUARD CLAMP 1
36 MIGB/T2671.2 M6X20 SCREW M6X20 2
37 MITBC431D.05.00-2A RUBBER HANDLE 1
38 MITBC431D.05.00-1A AL TUBING 1
39 MIGB/T2671.2 M5X25 SCREW M5X25 4
40 MITBC431D.05.03-3A UPPER CLAMP 1
41 MITBC431D.05.03-1A MIDDLE CLAMP 1
42 MITBC431D.05.03-2A LOWER CLAMP 1
43 MIGB/T2671.2 M5X25 SCREW M5X25 2
44 MITBC431D.05.01-00A CONTROL HANDLE ASSEMBLY 1
45 MIGB/T2671.2 M5X30 SCREW M5X30 1
46 MIGB/T97.1 M5 WASHER M5 1
47 MITBC431D.05.01-2A THROTTLE HOUSING LH 1
48 MITBC431D.05.01-5 LOCK TRIGGER 1
49 MITBC431D.05.01-7 CONDUIT 1
50 MITBC431D.05.07-00 WIRE CABLE A 1
51 MITBC431D.05.08-00 WIRE CABLE B 1
52 MITBC431D.05.05-00 THROTTLE CABLE ASSEMBLY 1
53 MIGB/T6170 M5 NUT M5 1
54 MIGB/T845 ST3.5X9.5 ST SCREW 3.5X9.5 2
55 MIGB/T845 ST4.2X10 ST SCREW 4.2X10 4
56 MITBC431D.05.01-1A THROTTLE HOUSING RH 1
57 MITBC431D.05.01-4 SPRING - TRIGGER 1
58 MITBC431D.05.01-3 TRIGGER 1
59 MITBC431D.05.01-6 SPRING - TRIGGER 1
60 MIYD38-3.01.11.04-00 ON/OFF SWITCH 1
61 MITBC431D.02.00-2 BLADE COVER 1
62 MITBC430D.02.01-00 NYLON HEAD ASSY 1
63 MIC43.1100.0001 BLADE 1
