360UX, 460UVX Premium Brushcutter
32
Original Instructions Version November 17
360UX/460UVX_1011171
360UX Parts - Engine Unit
ID PART NUMBER DESCRIPTION
58 MIGB/T97.1 M8 FLAT WASHER M8
59 MIC36.1101.0600 PAWL ASSEMBLY
60 MIGB/T6175 M8 NUT M8
61 MIC36.1110.0000 STARTER ASSEMBLY
62 MIGB/T2672 M5X14 SCREW M5X14
63 MIGB/T96 M5 PLATE WASHER M5
64 MIC43.2110.0006 RATCHET WHEEL
65 MIC36.1110.0005 SPRING
66 MIC43.2110.0003 RECOIL PULLEY
67 MIC43.2110.0004 SPRING HOUSING
68 MIA36.0110.0003 RECOIL SPRING
71 MIA45.0110.0006 STARTER ROPE
72 MIA41.1110.0003 STARTER GRIP
73 MIA45.0111.0200 TANK VENT
74 MIC36.1107.0003 VENT PIPE
75 MIC36.1107.0002 RETURN PIPE
76 MIC43.1107.0003 TANK GROMMET
77 MIC36.1107.0001 FUEL PIPE
78 MIA42.1111.0300 TANK CAP ASSEMBLY
79 MIC36.1107.0000 FUEL TANK ASSEMBLY
80 MIA38.0311.0500 FUEL FILTER
81 MIA45.0102.0103 CLAMP
82 MIC36.1101.0009 FUEL TANK HOUSING
83 MIC36.1108.0100 CLUTCH DRUM
84 MIGB/T893.1 35 CIRCLIP 35
85 MIGB/T276 6202-
2RSP5
BEARING 6202-2RS
86 MIC36.1101.0004 PLATE
87 MIC36.1108.0001 CLUTCH DRUM HOUS-
ING
88 MIGB/T894.1 15 CIRCLIP 15
ID PART NUMBER DESCRIPTION
89 MIC45.6808.0001 AV RUBBER
90 MIC45.6808.0002 CLAMP
91 MIGB/T2671.2
M6X25
SCREW M6X25
92 MIGB/T893.1 45 CIRCLIP 45
92 MIC36.1101.0013 HEAT INSULATION
93 MIC36.1101.0014 HEAT INSULATION A
94 MIC36.1101.0015 HEAT INSULATION B
95 MIC36.1101.0016 HEAT INSULATION C
96 MIC36.1101.0011 HOUSING SLEEVE
97 MIC36.1111.0106 CABLE CLIP
98 C36.1111.0106 CABLE CLIP
