460UVX Parts - Engine Unit
ID PART NUMBER DESCRIPTION
1 MIC36.1104.0001 SCREW
2 MIC36.1104.0002 AIR FILTER COVER
3 MIGB/T3452.1
3.63X2.62
O-RING
4 MIC36.1104.0200 AIR FILTER
5 MIGB/T2671.2
M5X45
SCREW M5X45
6 MIC36.1104.0004 AIR FILTER BASE
7 MIC36.1101.0100 CARBURETOR
8 MIGB/T2671.2
M5X25
SCREW M5X25
9 MIA38.0301.0010 CARB GASKET
10 MIC36.1101.0200 MANIFOLD
11 MIGB/T845 ST4X10 SCREW ST4X10
12 MIC36.1101.0002 INLET GASKET
13 MIC36.1101.0101 CHOKE LEVER
14 MIC36.1104.0005 COVER
15 MI01.01.4111 SCREW ST4.8X14
16 MIC36.1101.0003 SPARK PLUG COVER
17 MIA45.0806.0400 SPARK PLUG
18 MIC36.1101.0400 TOP HOUSING
19 MIGB/T2671.2
M5X14
SCREW M5X14
20 MIGB/T2671.2
M4X14
SCREW M4X14
21 MIC46.1101.0303 REAR COVER
22 MIC36.1101.0304 GASKET
23 MIC46.1101.0301 CYLINDER
24 MIC46.1101.0302 FRONT COVER
25 MIC36.1106.0200 IGNITION COIL
26 MIGB/T2671.2
M5X20
SCREW M5X20
27 MIC36.1106.0301 WIRE A
28 MIC36.1106.0302 WIRE B
29 MIC36.1101.0006 MUFFLER GASKET
30 MIC36.1101.0007 HEAT SHIELD
31 MIC36.1105.0000 MUFFLER
32 MIGB/T2671.2
M6X60
SCREW M6X60
33 MIC36.1101.0005 BASE GASKET
34 MIC46.1103.0002 PISTON RING
35 MIA38.0303.0003 PISTON PIN CIRCLIP
36 MIC43.0103.0300 BEARING
37 MIC46.1103.0001 PISTON
38 MIC46.1103.0003 PISTON PIN
39 MIC36.1101.0008 FUEL TANK GUARD
40 MIA62.0113.0005 INSULATION
41 MIGB/T2671.2
M5X16
SCREW M5X16
42 MIC36.1101.0010 CLUTCH BOLT
43 MIGB/T755 M10 WASHER M10
44 MIC36.1101.0501 CLUTCH ASSEMBLY
45 MIC43.0101.0009 FLAT WASHER
46 MIGB/T6187 M8 FLANGE NUT M8
47 MIC36.1106.0100 FLYWHEEL
48 MIGB/T119 B5X10 PIN 5X10
49 MIC43.0101.0300 OIL SEAL
50 MIC36.1102.0002 CRANKCASE L/H
51 MIGB/T276 6202-
2RSP6
BEARING 6202 P6
52 MIC36.1102.0003 GASKET
53 MIGB/T1099
3X5X13
KEY
54 MIC36.1103.0100 CRANKSHAFT ASSEMBLY
55 MIC36.1102.0001 CRANKCASE R/H
