360UX, 460UVX Premium Brushcutter
40
Original Instructions Version November 17
360UX/460UVX_1011171
460UVX Parts - Shaft Assembly
ID PART NUMBER DESCRIPTION
1 MIC36.1100.0100 SHAFT ASSEMBLY
3 MIC36.1111.0101 VIBRATION COVER
4 MIC36.1111.0102 SIDE COVER
5 MIC36.1111.0103 UPPER COVER
6 MIC36.1111.0104 HARNESS PLATE
7 MIC36.1111.0105 SUPPORT SEAT
8 MIGB/T6564
ST4.8X12
SCREW ST4.8X12
9 MIGB/T6564
ST4.8X19
SCREW ST4.8X19
10 MIC43.2111.0306 AV SPRING
11 MIC43.2111.0307 SLEEVE
12 MIC43.2111.0308 SLEEVE
13 MIC43.2111.0310 CLAMP
14 MIGB/T2671.2
M5X16
SCREW M5X16
15 MIGB/T41 M8 NUT M8
16 MIC36.1111.0106 CABLE CLAMP
17 MIGB/T96.1 M5 WASHER M5
18 MIC36.1111.0201 UPPER CLAMP
19 MIC36.1111.0202 LOWER CLAMP
20 MIC27.6111.0205 LOCK KNOB
21 MIGB/T5782
M8X60
SCREW M8X60
22 MIGB/T96.1 M8 PLATE WASHER M8
23 MIC43.2111.0001 HANDLE TUBING
24 MIC43.2111.0201 GRIP
25 MIC43.2111.0202 LEFT HANDLE CLAMP
26 MIGB/T2671.2
M5X45
SCREW M5X45
27 MIGB/T56 M5 NUT M5
28 MIC24.0113.0101 UPPER GUARD
29 MIC24.0113.0105 LOWER GUARD
30 MIC24.0113.0104 CUTTING BLADE
31 MIGB/T6564
ST4.2X13
SCREW ST4.2X13
32 MIC43.2113.0309 SCREW ST4.8X19
33 MIC43.2113.0305 GUARD CLAMP
34 MIC43.2113.0307 LOCK SCREW
35 MIGB/T2671.2
M6X12
SCREW M6X12
36 MIGB/T2671.2
M6X25
SCREW M6X25
37 MIC48.B116.0000 GEAR CASE ASSEMBLY
37-1 MIGB/T893.1 28 CIRCLIP 28
37-2 MIGB/T894.1 12 CIRCLIP 12
37-3 MIGB/T276 6001-
2Z
BEARING 6001-2Z
37-4 MIC48.B116.0002 PINION GEAR
37-5 MIGB/T5781 M6X8 SCREW M6X8
37-7 MIGB/T276 6000-
2Z
BEARING 6000-2Z
37-8 MIC43.B116.0004 GEAR
37-9 MIC43.B116.0003 GEAR SHAFT
37-10 MIGB/T276 6002-
2RSP5
BEARING 6002-2RS
37-11 MIGB/T893.1 32 CIRCLIP 32
37-12 MIC43.B116.0006 HOLDER A
37-13 MIC43.B116.0005 HOLDER B
37-14 MIC43.B116.0007 NUT PROTECTOR
37-15 MIGB/T6177.2
M10X1.25
FLANGE NUT
M10X1.25
38 MI TBC NYLON HEAD AS-
SEMBLY
39 MIC43.1100.0001 BLADE
