Mitox 430U - TECHNICAL SPECIFICATION

TECHNICAL SPECIFICATION
MODELS Mitox 260 Mitox 330 Mitox 430
Dry weight (without cutting tools and gasoline.) 5.8 kg 6.7 kg 7.4 kg
Fuel tank capacity: (litres) 0.7 l 0.75 l 1.1l
Blade diameter: (mm) 255 255 255
Blade thickness: (mm) 1.4 1.4 1.4
Number of teeth 3 3 3
Fixation hole diameter: (mm) 25.4 25.4 25.4
Max. blade rotation speed: rpm (min
–1
) 9000 9000 9000
Rotation direction (as seen from above) Counter
Clockwise
Counter
Clockwise
Counter
Clockwise
Cylinder displacement: ( cm
3
) 25.4 32.6 42.7
Power max.: (kw) in accordance with ISO 8893 0.75 0.9 1.25
Engine speed at max. power: rpm (min
–1
) 7000 6500 6500
Shaft speed: rpm (min
–1
) 7000 6500 6500
Idle speed engine level: rpm (min
–1
) 2500 2500 2500
Specific fuel consumption at max. power
(g/kW*h) in accordance with ISO 8893
≤580 ≤650 ≤660
Acoustic pressure level (lp a av) in dB
In accordance with EN 27917
98 dBA 96 dBA 96dBA
Acoustic power level (lw a av) en dBA
In accordance with EN 10883
109dBA 107dBA 107dBA
Acoustic power level guaranteed LwA
In accordance with Directive 2000-14/CE
112dBA 110 dBA 110dBA
Vibration level at min. level ( m/s 2)
In accordance with ISO 7916
1.10 1.20 1.20
Vibration level at full load ( m/s 2 )
In accordance with ISO 7916
8.8
7.5 7.5
