CS450X / CS500X / CS560X PREMIUM
22
Original Instructions Version July 16
CS450X-CS500X-CS560X_190716
Periodical Service Points
Cylinder Fins
Dust clogging between the cylinder fins will cause
overheating of the engine.
Periodically check and clean the cylinder fins after
removing the cylinder cover.
When installing the cylinder cover, make sure that
switch wires and grommets are fitted correctly.
Fuel filter
Using a wire hook, take out the filter (1) from the filler
port.
Disassemble the filter and clean with petrol, or
replace with a new one if needed.
Spark plug
Clean the electrodes with a wire brush and reset the
gap to 0.65 mm as necessary.
Plug type: NGK: BPRM7
Sprocket
Check for cracks and for excessive wear interfering
with the chain drive. If the wear is considerable,
replace it with a new one. Never fit a new chain on a
worn sprocket, or a worn chain on a new sprocket.
To Next Page
