CS450X / CS500X / CS560X PREMIUM
31
Original Instructions Version July 16
CS450X-CS500X-CS560X_190716
CS450X Parts - Base Unit
ID PART NUMBER DESCRIPTION QTY
1 MITCS4600.04.00-00 CHAINBRAKE ASSY 1
2 MIYD38-3.04.00-16 SCREW M5X40 1
3 MIYD38-3.04.00-13 SLEEVE 1
4 MIYD38-3.04.00-12 SLEEVE 1
5 MIGB/T119.2 3X14 PIN 3X14 1
6 MIYD45.04.00-24 TENSIONER SCREW 1
7 MIYD45.04.00-25 TENSIONER PAWL 1
8 MIYD45.04.00-11 TENSIONER COVER PLATE 1
9 MIGB/T845 ST4.2X9.5 TAPPING SCREW ST4.2X9.5 4
10 MITCS4600.04.00-2 CHAIN BRAKE LEVER 1
11 MIYD38-3.04.00-9 CHAIN BRAKE TORSION 1
12 MIYD45-3.04.00-13 WASHER 5.2X20X1.2 1
13 MIGB/T6183.1 M5 NUT M5 1
14 MIYD38-3.04.00-6 CAP 1
15 MIYD38-3.04.00-5 COMPRESSION SPRING 1
16 MIYD38-3.04.00-4 BLOCK 1
17 MIYD38-3.04.00-3 ACTUATOR 1
18 MIGB/T119.2 3X9 PIN 3X9 3
19 MIYD45-3.04.00-14 BRAKE CONTROL ROD 1
20 MIYD45-3.04.00-9 BRAKE SPRING 1
21 MIYD45-3.04.00-10A BRAKE BAND 1
22 MIYD45-4.04.00-1 BRAKE SPRING COVER 1
23 MIYD45.04.00-26 TENSIONER GEAR 1
24 MIYD45.01.00-16 CHAIN GUIDE BLOCK 1
26 MITCS4600.04.00-7 DUST SHEILD 1
27 MIYD38-3.04.00-7 SPRING 1
28 MIYD38-3.04.02-00 BRACKET 1
29 MIGB/T6177.1 M8 NUT M8 2
30 MITCS4600.05.01-00 AIR FILTER LOCK NUT 1
31 MITCS4600.00.00-1 AIR FILTER COVER 1
32 MIGB/T2672 M5X16 SCREW M5X16 9
33 MITCS4600.05.00-00 TOP COVER C/W HEAT 1
34 MITCS4600.00.00-6
ADJUSTER GROMMET 1
35 MITCS4600.02.00-1 GUIDE FLOW COVER 1
ID PART NUMBER DESCRIPTION QTY
36 MITCS4600.02.00-00 RECOIL STARTER ASSY 1
37 MIGB/T845 ST4.8X14 TAPPING SCREW ST4.8X14 1
38 MIGB/T96 M5 WASHER M5 1
39 MIYD45.02.00-2 RECOIL PULLEY 1
40 MIYD45.02.00-5 RECOIL SPRING 1
41 MIYD38-5.02.00-4 RECOIL HANDLE 1
42 MIYD45.02.00-7 RECOIL ROPE 1
44 MIYD45.03.00-1 ANTI-VIBRATION RUBBER 1
45 MIYD46.03.01-00 FUEL TANK 1
46 MIYD45.03.02-00 ANTI-VIBRATION RUBBER 2
47 MIYD50.00.00-9 SCREW 2
48 MIYD45.00-00-2 DUST COVER 2
51 MITCS4600.03.02-00 FUEL CAP ASSY 1
52 MIYD45.03.00-2 FUEL PIPE 1
53 MIYD45.03.00-15 FUEL CLIP 1
54 MIYD45.03.03-00 FUEL FILTER 1
55 MIYD04.01.07.07208 BREATHER 1
56 MIYD38-3.03.00-3 BREATHER GROMMET 1
57 MIYD45.03.00-25 THROTTLE ROD 1
58 MIYD45.03.00-11 TRIGGER 1
59 MIYD45.03.00-12 SAFETY TRIGGER SPRING 1
60 MIGB/T119.2 6X22 PIN 6X22 1
61 MITCS4600.03.04-00 REAR HANDLE GRIP 1
62 MIYD45.03.00-13 SAFETY LOCK TRIGGER 1
63 MIGB/T845 ST4.2X22 TAPPING SCREW ST4.2X22 1
64 MIYD38-3.01.11.04-00 ON/OFF SWITCH 1
65 MIYD45-2.06.00-00 USE MIYD45.06.00-01 1
66 MIGB/T845 ST4.8X16 TAPPING SCREW ST4.8X16 4
67 MIYD45-4.03.00-11 FUEL PIPE 1
68 MIYD45-4.03.00-13 FUEL PIPE 1
69 MIYD38-3.03.00-4A PRIMER ASSY 1
70 OR66EX21BPX CHAIN LOOP (66EX21BPX) 1
71 MI168PXBK095
GUIDE BAR (168PXBK095) 1
72 MIBARCOVER-16 GUIDE BAR COVER 16" 1
