CS450X / CS500X / CS560X PREMIUM
34
Original Instructions Version July 16
CS450X-CS500X-CS560X_190716
CS450X Parts - Engine Unit
ID PART NUMBER DESCRIPTION QTY
69 MIGB/T2672 M5X50 SCREW M5X50 2
70 MIYD45.01.01.02-1 R/H CRANKCASE 1
71 MIYD45.01.00-6 DUST PLATE 1
72 MIGB/T119.2 5X10 PIN 5X10 3
73 MIYD38-3.01.11.03-00 GROUND WIRE 1
74 MIYD45.01.00-10 ANTI-VIBRATION MOUNT 1
75 MIGB/T6191 M5X25 SCREW M5X25 5
76 MIYD45.01.00-20 SEAL SHIELD 1
77 MIGB/T93 M4 WASHER M4 2
78 MIGB/T2672 M4X8 SCREW M4X8 2
79 MIGB/T2672 M4X10 SCREW M4X10 4
80 MIYD45.01.10.01-00a FLYWHEEL ASSEMBLY 1
81 MIGB/T6177.2 M8X1 NUT M8X1 1
84 MITCS4600.03.03-00 OIL CAP ASSY 1
85 MIYD45.01.01.01-3 CIRCLIP 2
86 MIYD45.01.01.01-2 OIL PIPE 2.5X6X105 1
87 MIYD45.01.01.03-00 VACUUM JOINT 1
88 MIYD45.01.01.01-1 L/H CRANKCASE 1
89 MIGB/T893.1 35 CIRCLIP (SIZE 35) 1
90 MIYD45.01.00.08-00 OIL SEAL 15X35X4.5 1
91 MIYD45.01.11.01-00 IGNITION COIL 1
92 MIYD45-7.01.11.02-00 GROUND WIRE 1
93 MITCS4600.01.11-3 IGNITION SHIELD 1
94 MIYD45.00.00-9 DUST COVER 2
95 MIYD45.01.01-1 CRANKCASE GASKET 1
96 MIYD45.01.00-18 DAMPER 1
97 MIYD06.06.186 DECOMPRESSOR 1
98 MID20-WAT CARB GASKET KIT 1
