CS450X / CS500X / CS560X PREMIUM
45
Original Instructions Version July 16
CS450X-CS500X-CS560X_190716
CS560X Parts - Engine Unit
ID PART NUMBER DESCRIPTION QTY
1 MIYD50.01.02-1 CYLINDER (SQ.PORT) 1
2 MIGB/T6170 M5 NUT M5 2
3 MIGB/T93 M5 SPRING WASHER M5 15
4 MIGB/T97.1 M5 WASHER M5 13
5 MIYD45.01.09-1 MUFFLER COVER PLATE 1
6 MIYD45.01.09.01-00 MUFFLER 1
7 MIYD45.01.00-2 MUFFLER GASKET 1
8 MIYD45.01.00-24
MUFFLER CONNECTING
SCREW
2
9 MIGB/T6191 M5X20 SCREW M5X20 6
10 SPBPMR7A SPARK PLUG (BPMR7A) 1
11 MIYD50.01.02.03 SPRING 1
12 MIYD50.01.02.02 AIR INTAKE TUBE 1
13 MIGB/T2672 M5X12 SCREW M5X12 2
14 MIYD45.01.00-17 O-RING 1
15 MIYD45.01.00-1 CYLINDER GASKET 1
16 MIYD50.01.03-2 PISTON RING 2
17 MIA50.0103.0200 PISTON (EURO 2) 1
18 MIYD45.01.03-4 PISTON PIN CIRCLIP 2
19 MIA50.0103.0003 PISTON PIN (EURO 2) 1
20 MIYD45.01.03-5 NEEDLE BEARING RING 2
21 MIYD45.01.03.01-00 CRANKSHAFT 1
22 MIYD45.01.03.02-00
NEEDLE BEARING
11X15X12.5
1
23 MIGB/T1099 3X3.5X10
SEMI-CIRCULAR KEY
3X3.5X10
1
24 MIYD45.00.00-4
CONICAL ANTI-VIRATION
SPRING
1
25 MIYD45.00.00-3
ANTI-VIBRATION SPRING
BASE
1
26 MIGB/T845 ST4.8X16 TAPPING SCREW ST4.8X16 4
27 MIYD45.00.00.01-00 CHAIN CATCHER 1
28 MIGB/T2672 M5X16 SCREW M5X16 1
29 MIYD45.01.01.02-2 BREATHER JET 1
30 MIYD45.01.01.02-3 CIRCLIP 1
31 MIYD45.01.00-22 SPONGE BREATHER 1
32
MIYD45.01.00-21 FELLING SPIKE 1
33 MIGB/T2672 M5X10 SCREW M5X10 5
34 MIYD45.01.00.04-2 OIL FILTER SCREEN 1
ID PART NUMBER DESCRIPTION QTY
35 MIYD45.01.00.04-1 OIL FILTER 1
36 MIYD45.01.00-12 OIL TUBE 1
37 MIGB/T2672 M4X14 SCREW M4X14 2
38 MIYD45.01.15-00 OIL PUMP 1
39 MIYD45.01.00-23 SPONGE 1
40 MIYD45.01.00-13 OIL OUTLET PIPE 1
41 MIYD45.01.00-16 CHAIN GUIDE BLOCK 1
42 MIGB/T900 M8X26-8.8
DOUBLE-SCREW BOLT
AYM8-M8X26-8
2
43 MIYD45.01.13.01-00 CLUTCH ASSEMBLY 1
46 MIYD45.01.13.01-3 CLUTCH SPRING 1
47 MIYD45.01.00-19 CLUTCH ADJUSTING WASHER 1
48 MIYD45.01.00.10-00
NEEDLE BEARING
12X15X14.5
1
49 MIYD45.01.13-1 CLUTCH DRUM 1
50 MIYD45.01.00-26 SPROCKET RIM 1
51 MIYD45.01.00.06-00 WORM 1
52 MIYD45.01.00-15 COVER PLATE 1
53 MIYD45.01.00.09-00 OIL SEAL 15X28X4.5 1
54 MIGB/T276 6202D
BEARING 6202 GRADE D
15X35X11
2
55 MIYD45.01.00-8 CUSHION BLOCK 1
56 MIYD45.01.00-7 CHOKE ROD MOUNTING 1
57 MIYD45.01.00.03-00 CHOKE ROD 1
58 MIYD45.01.00-11 ANTI-VIBRATION MOUNT 1
59 MIYD45.01.00.07-00 ANTI-VIBRATION MOUNT 3
60 MIYD45.01.00.01-00 AIR INTAKE TUBE SUPPORT 1
61 MIYD45.01.00-4 TIE PLATE 1
62 MIYD45.01.00-3 SEALING PLATE 1
63 MIYD45.01.00-14 AIR INTAKE TUBE GASKET 1
64 MIYD45.01.06-00 CARBURETTOR 1
65 MIYD45.01.00.02-00 AIR INTAKE SOCKET 1
66 MITCS4600.01.08-00 AIR FILTER 1
67 MIGB/T899 GM5-M5X30 DOUBLE-SCREW BOLT 1
68 MIYD45.01.00-5 CUSHION
1
69 MIGB/T2672 M5X50 SCREW M5X50 2
70 MIYD45.01.01.02-1 R/H CRANKCASE 1
71 MIYD45.01.00-6 DUST PLATE 1
