100
Adjustment of the output torque (current) of the motor
5.4.4 Slip compensation (Pr. 245 to Pr. 247)
 Slip compensation is validated when the motor rated slip calculated by the following formula is set in Pr. 245. Slip
compensation is not made when Pr. 245 = "0" or "9999".
When V/F control or General-purpose magnetic flux vector control is performed, the inverter output current may be
used to assume motor slip to keep the motor speed constant.
Parameter
Number
Name Initial Value Setting Range Description
245 Rated slip
9999
0.01 to 50% Rated motor slip.
0, 9999 No slip compensation
246
Slip compensation time
constant
0.5s 0.01 to 10s
Slip compensation response time. When the
value is made smaller, response will be faster.
However, as load inertia is greater, a
regenerative overvoltage fault (E.OVîš…) is more
liable to occur.
247
Constant-power range
slip compensation
selection
9999
0
Slip compensation is not made in the constant
power range (frequency range above the
frequency set in Pr. 3)
9999
Slip compensation is made in the constant power
range.
The above parameters can be set when Pr. 160 User group read selection = "0". (Refer to page 167)
Rated slip =
Synchronous speed at base frequency - rated speed
× 100[%]
Synchronous speed at base frequency
REMARKS
 When performing slip compensation, the output frequency may become greater than the set frequency. Set the Pr. 1 Maximum
frequency value a little higher than the set frequency.
 Slip compensation is always valid when Advanced magnetic flux vector control is selected, the Pr. 245 to Pr. 247 settings are
invalid.
Parameters referred to
Pr. 1 Maximum frequency Refer to page 105
Pr. 3 Base frequency Refer to page 107
V/F
V/F
GP
MFVC
GP
MFVC
To Next Page
