4. SETTING AND PROCEDURE BEFORE OPERATION MELSEC-A
4-8
4.5 Station Number Setting
The buffer memory address of the master module in which control I/O signal information and
read/write data are stored, is determined depending on the station number setting on the AJ65BT-
68TD.
For details, refer to AJ61BT11/A1SJ61BT11 CC-Link System Master Local Module User's Manual or
AJ61QBT11/A1SJ61QBT11 CC-Link System Master Local Module User's Manual.
4.6 Orientation of Module Installation
The following shows the possible orientation for AJ65BT-68TD installation.
Panel
When installing alongside the panel When installing on the panel
