[ III Specification ]
- 10 -
HWE1706A GB
2. Electrical parts specifications
12 VDC Stepping motor
0~1800 pulse
12 VDC Stepping motor
0~1800 pulse
12 VDC
Stepping motor
0~1800 pulse
LEV
MF1, 2
Model
Parts name
TH21 Resistance 0˚C/15 kΩ, 10˚C/9.6 kΩ, 20˚C/6.3 kΩ, 25˚C/5.4 kΩ, 30˚C/4.3 kΩ, 40˚C/3.0 kΩ
TH22 Resistance 0˚C/15 kΩ, 10˚C/9.6 kΩ, 20˚C/6.3 kΩ, 25˚C/5.4 kΩ, 30˚C/4.3 kΩ, 40˚C/3.0 kΩ
FUSE 250 V 6.3 A
TB2 (L, N, ) 250 V 20 A
TB5
TB15
(M1, M2, S) 250 V 20 A
(1, 2) 250 V 15 A
8-pole, output 121 W
SIC-70CW-D8121-3
8-pole, output 244 W
SIC-101CW-D8244-3
10-pole, output 375 W
KMUC4E1MW or KMUC4E3MW
Symbol
TH23 Resistance 0˚C/15 kΩ, 10˚C/9.6 kΩ, 20˚C/6.3 kΩ, 25˚C/5.4 kΩ, 30˚C/4.3 kΩ, 40˚C/3.0 kΩ
PEFY-
P40VMHS-E
PEFY-
P50VMHS-E
PEFY-
P63VMHS-E
PEFY-
P71VMHS-E
PEFY-
P80VMHS-E
PEFY-
P100VMHS-E
PEFY-
P125VMHS-E
PEFY-
P140VMHS-E
Room
temperature
thermistor
Liquid pipe
thermistor
Gas pipe
thermistor
Fuse
(
Indoor controller
board
)
Fan motor (with
Inner-thermostat
)
Linear
expansion valve
Power supply
terminal bed
Transmission
terminal bed
