[ VIII Disassembly Procedure ]
- 29 -
HWE1706A GB
6. Sensor position
Liquid sensor
Liquid sensor
Liquid sensor
Gas sensor
Liquid sensor
Gas sensor
Gas sensor
Gas sensor
Liquid sensor
Gas sensor
PEFY-P40, 50, 63VMHS-E
PEFY-P125VMHS-EPEFY-P71, 80VMHS-E
PEFY-P140VMHS-E
PEFY-P100VMHS-E
HWE1706A.book 29 ページ ２０２０年６月２９日　月曜日　午後１時５６分
