Mitsubishi Electric CITY MULTI PFFY-P20VCM-E User Manual

[ III Specfications ]
- 5 -
HWE18160 GB
III Specfications
[1] Specifications
1. Specfications
*1 Cooling/Heating capacity indicates the maximum value at operation under the following condition.
Cooling: Indoor 33°CDB/28°CWB, Outdoor 33°CDB. The set temperature of the remote controller is 18°C.
Heating: Indoor 0°CDB/-2.9°CWB, Outdoor 0°CDB/-2.9°CWB. The set temperature of the remote controller is 25°C.
*2 The values in ( ) show the height of unit with leg.
*3 The external static pressure is set to 10Pa at factory shipment.
*4 The noise level in operation is measured at 1.5m apart from the front side and the bottom side of the unit in anechoic room.
(Noise meter A-scale value) Connect the duct of 1m in length to the air outlet.
Model name PFFY-
P20VCM-E
PFFY-
P25VCM-E
PFFY-
P32VCM-E
Power source ~ 220-240V 50Hz/60Hz
Cooling capacity
*1
kW
2.2 2.8 3.6
Heating capacity
*1
2.5 3.2 4.0
Power consumption Cooling
kW
0.022 0.026 0.031
Heating 0.022 0.026 0.031
Current Cooling
A
0.25 0.30 0.34
Heating 0.25 0.30 0.34
External finish Galvanized steel plate
Dimension Height
*2
mm
615 (690)
Width 700
Depth 200
Net weight kg 18 18 18.5
Heat exchanger Cross fin (Aluminum fin and copper tube)
Fan Type x Quantity Sirocco fan x 2
Airflow rate
(Lo-Mid-Hi)
m
3
/min 5.0-6.0-7.0 5.5-6.5-8.0 5.5-7.0-8.5
External static pressure
*3
Pa 0/10/40/60
Motor Type DC motor
Output kW 0.096
Air filter PP honeycomb fabric.
Refrigerant
pipe diameter
Gas (Brazed) mm ø6.35
Liquid (Brazed) mm ø12.7
Drain pipe dimensions mm 32 (1-1/4 inch)
Noise level (Lo-Mid-Hi)
dB (A) 21-23-26 22-25-29 23-26-30
