[ IV Outlines and Dimensions ]
- 8 -
HWE18160 GB
IV Outlines and Dimensions
[1] Outlines and Dimensions
1. PFFY-P20, 25, 32, 40, 50, 63VMC-E Bottom suction ꞏ wall mounting
Unit: mm
Front
Bottom view
Top view
view
Right side
view
Air inlet
Air outlet
Duct mounting holes
Wall mounting holes
Duct mounting holes
(Power source)
(Transmission)
(Power source wiring)
(Transmission wiring)
(Gravity drain)
Note 1. Use an M10 screw for the wall and floor mounting bolt (field supply).
2. This drawing is for PFFY-P63VCM-E model, which have 4 fans.
PFFY-P40·50VCM-E models have 3 fan.
PFFY-P20·25·32VCM-E models have 2 fan.
DEFACB
2
Liquid pipe
ø9.52ø15.88
900
1100
1
Gas pipe
PFFY-P40 · 50VCM-E
PFFY-P63VCM-E
956
1156
756
1002
1202
802
800
1000
600
9
11
7700
PFFY-P20 · 25 · 32VCM-E
Model
ø6.35ø12.7
860
1060
660
A
B(Wall mounting hole pitch)
C
23
51
100
100×(E-1)=F
D(Duct)
30
20
2×E-ø2.9 holes
50.5
10
528(Wall mounting hole pitch)
4-14×30 Slot
Drain pipe (O.D.ø32)
2×2-ø2.9 holes
150 25
200
100 15
655
615 23
94
65
172
98
274
136.5
100
22
Brazing connection (liquid)
Brazing connection (gas)
Terminal block
Terminal block
Knockout hole ø28
Knockout hole ø28
Air filter
Control box
2 Refrigerant piping
1 Refrigerant piping
HWE18160.book 8 ページ ２０１９年２月１８日 月曜日 午前９時５９分
