– 7 –
GB
In COOL, DRYING, HEAT, and AUTO (single set point) modes
Pressing the button increases the preset temperature.
Pressing the button decreases the preset temperature.
In AUTO (dual set point) and SETBACK modes
* During the preset temperature setting, the setting will automatically turn off if the or
button is left untouched for a certain period of time.
Preset temperature
TEMP.
TEMP.
Room
Set to
AUTO COOLHEATFAN
DRYING VENTI. SETBACK
Cooling preset temperature
Heating preset temperature
Current operation mode
Current preset temperature (cooling/heating) appears.
* The example shows the display in AUTO (dual set point) mode.
When the or button is pressed, the preset temperature
(cooling/heating) display blinks.
Room
Set to
AUTO COOLHEATFAN
DRYING VENTI. SETBACK
While the preset temperature (cooling/heating) display blinks, pressing the
button increases the preset temperatures for both cooling and heating,
and pressing the button decreases the preset temperatures for both
cooling and heating.
When the button is pressed, only the cooling preset temperature display
blinks.
TEMP.
Room
Set to
AUTO COOLHEATFAN
DRYING VENTI. SETBACK
While the cooling preset temperature display blinks, pressing the button
increases the cooling preset temperature, and pressing the button
decreases the cooling preset temperature.
When the button is pressed, only the heating preset temperature display
blinks.
Room
Set to
AUTO COOLHEATFAN
DRYING VENTI. SETBACK
While the heating preset temperature display blinks, pressing the
button increases the heating preset temperature, and pressing the
button decreases the heating preset temperature.
Pressing the button completes the preset temperature setting.
TEMP.
WT06428X01_GB.fm Page 7 Friday, December 16, 2011 9:51 AM
To Next Page
