8
4 SPECIFICATIONS
ServiceRef.
PUZ-A12NKA7
PUZ-A12NKA7-BS
PUZ-A18NKA7
PUZ-A18NKA7-BS
PUZ-A24NHA7
PUZ-A24NHA7-BS
PUZ-A30NHA7
PUZ-A30NHA7-BS
PUZ-A36NKA7
PUZ-A36NKA7-BS
PUZ-A42NKA7
PUZ-A42NKA7-BS
Power
supply
Phase Single
Cycle 60Hz
Voltage 208/230V
MCA
A 11 11 19 19 25 25
MOCP
A 28 28 26 26 31 31
Breakersize
A 15 15 25 25 30 30
Externalnish
Munsell3Y7.8/1.1
Heatexchanger
Crossn
Defrostmethod
Reversecycle
Crankcaseheater
kW ―
Compressor
Hermetic
Model
SNB092FNCM SNB130FBCM2 SNB172FWHM1 SNB172FWHM1 MNB33FBRMC-L MNB33FBRMC-L
Motoroutput
kW 0.65 0.9 1.2 1.2 2.5 2.5
R.L.A
7 7 7 7 8 8
L.R.A
12 12 11 11 13 13
Startertype
Inverter
Fan Fan(drive)×No.
Propellerfan×1 Propellerfan×1 Propellerfan×1 Propellerfan×1 Propellerfan×2 Propellerfan×2
Fanmotoroutput kW 0.046 0.046 0.086 0.086 0.074+0.074 0.074+0.074
Fanmotor F.L.A 0.5 0.5 0.4 0.4 0.50+0.50 0.50+0.50
Airow CFM 1,590 1,590 1,940 1,940 3,880 3,880
K/min 45 45 55 55 110 110
Sound
pressurelevel
Cooling dB
44 44 47 47 52 52
Heating dB 46 46 48 48 53 53
Protectiondevices HPswitch HPswitch HPswitch HPswitch HPswitch HPswitch
Comp.shellthermo Comp.shellthermo Comp.shellthermo Comp.shellthermo Comp.shellthermo Comp.shellthermo
Dimension W inch 31-13/16+2-7/16 31-13/16+2-7/16 37-12/32 37-12/32 41-5/16 41-5/16
D inch 11-3/16 11-3/16 13+1-3/16 13+1-3/16 13+1-3/16 13+1-3/16
H inch 24-13/16 24-13/16 37-1/8 37-1/8 52-11/16 52-11/16
W mm 809+62 809+62 950 950 1050 1050
D mm 300 300 330+30 330+30 330+30 330+30
H mm 630 630 943 943 1338 1338
Weight lb 93 100 153 153 214 214
kg 42 45 69 69 97 97
Refrigerant R410A R410A R410A R410A R410A R410A
Charged lb 4+7/16 4+14/16 7+11/16 7+11/16 10+6/16 10+6/16
kg 2.0 2.2 3.5 3.5 4.7 4.7
Control Linearexpansionvalve
Oilcharged Model Ether(FV50S)
oz 12 16 23 23 45 45
L
0.35 0.5 0.7 0.7 1.4 1.4
Refrigerant
piping
PipesizeODliquid inch 1/4 1/4 3/8 3/8 3/8 3/8
mm 6.35 6.35 9.52 9.52 9.52 9.52
PipesizeODgas inch 1/2 1/2 5/8 5/8 5/8 5/8
mm 12.7 12.7 15.88 15.88 15.88 15.88
Connectionmethod-Indoor Flared
Connectionmethod-Outdoor Flared
Heightdifference
IU-OU
ft Maximum100
m Maximum30
Pipinglength ft
Maximum100 Maximum100 Maximum165 Maximum165 Maximum165 Maximum165
m Maximum30 Maximum30 Maximum50 Maximum50 Maximum50 Maximum50
OCH636A
