12-11
Coolant level
Check that the coolant level is between the
“FULL” and “LOW” marks on the reservoir
tank.
P. 12-52
V-belt tension and damage
Check the belt for proper deflection when a
force of 98 N (22 lbs., 10 kgf) is applied to the
point midway between the pulleys.
Check also that the belt is not nicked or other-
wise damaged.
P. 12-57
Engine oil level
Check that there is sufficient engine oil using
the oil level gauge or oil level check button.
Change the engine oil if its level is above the
round hole on the oil level gauge.
P. 12-24
Leakage of coolant, fuel and oil
Check the underneath of the vehicle for any
sign of leakage.
Z11188
Z10749
Z17815
Z10751
FE_FG.book Page 11 Wednesday, January 14, 2009 7:08 PM
