12-13
Service brake pedal
Make sure that the brake pedal has 0.1 to 3
mm (0.0039 to 0.12 in.) free play when
pressed by finger.
Check also that when the brake pedal is fully
depressed, there is a gap of 20 mm (0.79 in.)
or more between the pedal and the floor.
P. 12-62
Clutch pedal free play
<Manual transmission vehicles>
With your hand, depress the clutch pedal and
make sure that it has 0.2 to 4 mm (0.0079 to
0.16 in.) of free play.
P. 12-65
Brake fluid level
Check that the brake fluid level is between the
“MAX” and “MIN” marks on the reservoir tank.
P. 12-38
Windshield washer fluid level
Confirm that the windshield washer fluid level
is above the bottom of the inspection window.
P. 12-81
Z11955
Z11945
Z10682
Z11946
FE_FG.book Page 13 Wednesday, January 14, 2009 7:08 PM
