13-13
B12 10A Automatic transmission
B13 15A Tester
B14 20A Headlamps (high beam)
B15 20A Left headlamp (low beam)
B16 20A
Right headlamp
(low beam)
B25 15A Tail lamps
B27 10A Horn
B28 10A Air conditioner
B29 25A
Air conditioner condenser
fan
B30 30A
Air conditioner blower fan,
heater blower fan
B33 10A Van body dome light
B34 20A
Automatic transmission
fluid cooler fan
B36 20A Engine drive unit
M1 10A Backup lamps
M2 10A Meter cluster
M3 15A Wipers
M4 10A
Auxiliary power supply
(starter switch ON circuit)
M5 10A Relay control
M6 10A Automatic transmission
M8 10A Exhaust brake
M9 5A Engine control unit
M10 10A MVCU
M11 10A ABS
S1 10A Starter
Fuse
No.
Amperage Protected circuit
