13-21
5. Remove the front and side turn signal lamp
toward the outside of the vehicle, then remove
the connector .
CAUTION
• When removing the front and side turn sig-
nal lamp, do not pull it forward (toward the
front of the vehicle) or its tabs could break.
• Do not open the door with the front and side
turn signal lamp moved outward (but not
completely removed) or the door could hit
and damage it.
6. Remove the screw at the bottom of the
dummy lamp , then remove the lamp toward
the outside of the vehicle.
7. Remove the headlamp’s bolts and connectors
.
CAUTION
• Do not turn the beam adjusting screw .
Turning the beam adjusting screw would
change the beam setting, thus creating a
nuisance for drivers of other vehicles. If you
accidentally turn the beam adjusting screw,
have an authorized dealer perform neces-
sary inspection.
• When setting down the removed headlamp,
place it on a soft cloth to avoid scratching
the lens.
Z11267
Z11268
Z11269
Z11270
