13-22 Useful advice for emergencies
8. Raise the headlamp slightly to remove the tabs
from the holes , then pull it out toward you.
• Headlamp installation
1. Insert the tabs on the headlamp into the
holes , and fit the headlamp in place.
2. Fit the headlamp’s bolts and connectors .
3. Pull out the screw in the vehicle.
4. Insert the stud pin on the dummy lamp into
the grommet hole , fit the dummy lamp in
place, and tighten the bottom screw .
CAUTION
Do not tighten the screw too tightly or the
mounting could get damaged.
Z11271
Z11272
Z11625
Z11273
FE_FG.book Page 22 Wednesday, January 14, 2009 7:08 PM
