13-24 Useful advice for emergencies
• Installation
1. Align the tabs on the bulb with the grooves ,
fit the bulb in place, and retain the bulb with the
spring.
2. If the packing is dirty, clean it. If the packing is
twisted, untwist it.
3. Securely press the connector into place.
4. Fit the cover by pressing it and turning it in the
direction of arrow .
1.3 Parking lamp bulb replacement
1. Turn the socket in the direction of the arrow
to remove it.
2. Remove the bulb .
3. Perform installation by following the removal
steps in reverse.
4. If the packing is dirty, clean it.
2 Front and side turn signal lamp bulb
replacement
1. Open the door.
2. Turn the socket in the direction of arrow to
remove it.
3. Press the bulb and turn it in the direction of
arrow to remove it.
4. Perform installation by following the removal
steps in reverse.
5. If the packing is dirty, clean it.
3 Interior lamp bulb replacement
3.1 Other than Crew-cab models
1. Insert a flat-blade screwdriver into the
notches and use it to release the tabs on
the bottom of the lens . Remove the lens.
2. Push the bulb retainer in the direction of the
arrow and remove the bulb .
3. To install the lens, insert the tabs on the bot-
tom of the lens, align the tabs on the top of the
lens, and press the lens into place.
Z11276
Z18699
Z11279
FE_FG.book Page 24 Wednesday, January 14, 2009 7:08 PM
