Mitsubishi 2033C SERIES - UPS Parts Location (7.5-20 kVA)

MITSUBISHI ELECTRIC 2033C SERIES UPS
MITSUBISHI
ELECTRIC
2033C SERIES UPS
OWNERS / TECHNICAL MANUAL
Page Number:
1-9
FIGURE 1.5a UPS Parts Location(7.5-20kVA)
4.Main PCB
UPFR-K
3.Relay PCB
RYDR-X
UPS module
FRONT VIEW
7.Maintenance bypass
transfer switch
52CS
Battery
5.AC input, AC
output terminal
Cooling fan
6.Grounding bar
Converter &
Inverter Uni
t
2.Display PCB
DPAU-72
1.LCD touch panel
monitor display
