1.4 Specifications
The UPS name plate displays the rated kVA as well as nominal voltages and currents. The
name plate is located on the interior side of the UPS front door.
TABLE 1.1 Power Specifications
Rated output
Power
Input voltage
3 phase / 4 wire
Output voltage
3 phase / 3 or 4 wire
7.5kVA/6kW
10kVA/8kW
15kVA/12kW
20kVA/16kW
30kVA/24kW
40kVA/32kW
50kVA/40kW
208
208
208
208
208
208
208
208
208
208
208
208
208
208
TABLE 1.2 UPS Module Information
UPS
(kVA)
CABLE
ENTRY
WIDTH
(in/mm)
DEPTH
(in/mm)
HEIGHT
(in/mm)
WEIGHT
(lb./kg)
HEAT LOSS
@ 208V
(kBTU/h)
7.5 BOTTOM 17.7 / 450 31.5 / 800 43.3 / 1100 562 / 255* 3.2
10 BOTTOM 17.7 / 450 31.5 / 800 43.3 / 1100 562 / 255* 3.9
15 BOTTOM 17.7 / 450 31.5 / 800 43.3 / 1100 816 / 370* 5.1
20 BOTTOM 17.7 / 450 31.5 / 800 43.3 / 1100 816 / 370* 6.5
30 BOTTOM 23.6 / 600 31.5 / 800 59.0 / 1500 1235 / 560* 8.8
40 BOTTOM 27.6 / 700 31.5 / 800 59.0 / 1500 1082 / 490 11.9
50 BOTTOM 27.6 / 700 31.5 / 800 59.0 / 1500 1082 / 490 14.6
*：7.5-30kVA Including batteries
