Licence plate lamps
E01004600943
1. When removing the lamp unit (A), push it to-
wards the left side of the vehicle body.
2. Remove the socket (B) and bulb assembly by
turning it anticlockwise.
3. Remove the bulb by pulling it out.
4. To
install the bulb, perform the removal
steps in reverse.
NOTE
l
When
installing the lamp, insert tab (C) first
then align and insert tab (D).
High-mounted stop lamp
E01004500593
NOTE
l
An
LED, not a bulb, is used in the high-moun-
ted stop lamp.
Contact a MITSUBISHI MOTORS Author-
ized Service Point when there is a need for re-
pair or replacement.
Maintenance
8-33
8
