NOTE
l
An
LED, not a bulb, is used in the stop lamp/
tail lamp.
Contact a MITSUBISHI MOTORS Author-
ized Service Point when there is a need for re-
pair or replacement.
3. Pull the bulb out of the socket.
4. To
install the bulb, perform the removal
steps in reverse.
NOTE
l
When mounting the lamp unit, align the
groove (D) on the lamp unit with the clip on
the body and the pin (E) on the unit with the
hole in the body.
Reversing lamps
E01004400332
1. Open the tailgate.
2. Insert
a straight blade (or minus) screwdriver
into the notch of the cover and pry gently to
remove the cover.
NOTE
l
Wrap
a piece of cloth around the tip of the
screwdriver in order to avoid scratching the
cover.
3. Remove
the socket and bulb assembly by turn-
ing it anticlockwise.
4. Remove the bulb by pulling it out.
5. To
install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lid, align the tab on the
lid with the hole on the vehicle side.
Maintenance
8-32
8
