Chapter 2 Specifications
2–3
HC Series (3000r/min. rating)
INC specifications: HC∗∗
∗∗∗∗
∗∗-E51/-E42/-E33, ABS specifications: HC∗∗
∗∗∗∗
∗∗-A51/-A42/-A33
Servomotor type
HC53 HC103 HC153 HC203 HC353 HC453 HC703
Rated output [kW] 0.5 1.0 1.5 2.0 3.5 4.5 7.0
Rated current [A] 3.2 5.3 8.6 10.4 16.5 22.1 30.5
Stall current [A] 5.8 9.8 15.9 22.4 33.3 57.3 67.2
Rated torque [N•m]
{[kgf•cm]}
1.59
{16.3}
3.18
{32.5}
4.77
{48.7}
6.37
{65.0}
11.1
{114}
14.3
{146}
22.3
{227}
Continuous
characteristics
Stall torque [N•m]
{[kgf•cm]}
2.94
{30.0}
5.88
{60.0}
8.82
{90.0}
13.7
{140}
22.5
{230}
37.2
{380}
49.0
{500}
Rated speed [r/min] 3000
Max. speed [r/min] 3000
Max. current [A] 17 28 47 64 85 113 141
Max. torque [N•m]
{[kgf•cm]}
8.82
{90.0}
16.7
{170}
28.4
{290}
40.2
{410}
55.9
{570}
79.8
{814}
105
{1072}
Power rate at continuous rated
torque [kW/sec]
3.8 7.4 11.4 9.5 15.0 16.9 29.3
Instantaneous angle acceleration
[rad/sec
2
]
7234 6970 14308 9459 6817 6593 6566
J [kg•cm
2
]
{[kgf•cm•sec
2
]}
6.6
{0.007}
13.7
{0.014}
20.0
{0.02}
42.5
{0.04}
82
{0.08}
121
{0.12}
160
{0.16}
Motor inertia
GD
2
[kgf•cm
2
] 26.5 54.8 79.8 170 328 484 640
J [kg•cm
2
]
{[kgf•cm•sec
2
]}
8.6
{0.009}
15.7
{0.016}
22.0
{0.022}
52.5
{0.054}
92
{0.094}
131
{0.134}
170
{0.173}
Motor inertia
with brakes
GD
2
[kgf•cm
2
] 34.5 62.8 87.8 210 368 524 680
Recommended motor shaft
conversion load inertia rate
5-times or less of motor inertia
Armature resistance (phase 20°C)
[Ω]
0.55 0.33 0.20 0.11 0.06 0.030 0.025
Armature inductance (20° between
wires) [mH]
5.7 3.6 2.2 3.9 2.1 1.2 0.9
Inductive voltage constant (20°C,
±10% between wires) [mV/rpm]
35.3 42.3 40.7 41.6 45.7 46.2 46.8
Torque constant (±10%)
[kgf•cm/Arms]
{[kgf•cm/Ap]}
6.0
{4.2}
7.2
{5.1}
6.9
{4.9}
7.0
{5.0}
7.7
{5.5}
7.8
{5.5}
7.9
{5.6}
Electrical time constant [msec] 5.1 5.5 5.4 17.2 17.4 20.1 15.4
Mechanical time constant [msec] 3.2 2.8 2.7 3.1 2.6 1.8 2.0
Thermal time constant[min]15202535455055
Static friction torque [N•m]
{[kgf•cm]}
0.13
{1.3}
0.18
{1.8}
0.20
{2.0}
0.16
{1.6}
0.21
{2.1}
0.40
{4.1}
0.50
{5.1}
Armature coil temperature upper limit
degree [deg]
100
Motor end detector
Resolution per motor rotation
E51/A51:1000000 pulse/rev, E42/A42:100000 pulse/rev, E33/A33:25000 pulse/rev
Structure Fully closed, self-cooling (protection method: IP65, IP67)
Environment conditions To follow section 3-1-1 Environment conditions
Weight With/without brakes [kg] 5.0/7.5 7.0/9.0 9.0/11 12/18 19/25 25/30 32/38
Armature insulation class Class F
(Caution) The above characteristic values are the representative values. The max. current and max. torque are the value when
combined with the amplifier.
