Chapter 5 Options
5–2
5-1 Option cable and connector
The cables and connectors that can be ordered from Mitsubishi Electric Corp. as option parts are shown
below. Cables can only be ordered in the designated lengths shown on the following pages. Purchase a
connector set, etc., to create special length cables when required. The power cable and brake cable
must be manufactured by the user with separately purchased wire, etc.
CAUTION
There is a limit to the applicable cable size to ensure the drip-proof properties of
the IP65 and IP67 specification connectors.
(2) Power supply connector
(3) Brake connector
(1) Detector cable and connector set
To Next Page
